ARRIS SBG7600AC2 Cable Modem Router | DOCSIS 3.0 AC2350 WiFi

ARRIS SURFboard SBG7600AC2 Cable Modem and WiFi Router Combo

The ARRIS SURFboard SBG7600AC2 combines a DOCSIS 3.0 cable modem and an AC2350 dual-band WiFi router in one compact device. It supports cable internet plans up to 800 Mbps and replaces both the modem and router rented from your service provider. With 32 downstream and 8 upstream channels, four Gigabit Ethernet ports, and WiFi coverage up to 2,200 square feet, the SBG7600AC2 is built for streaming, online gaming, video calls, and busy smart home networks.

Key Features

• All-in-one device: DOCSIS 3.0 modem and AC2350 dual-band WiFi router
• Supports plans up to 800 Mbps with 32 x 8 channel bonding
• Four Gigabit Ethernet ports for wired speeds up to 1 Gbps per port
• Dual-band WiFi on the 2.4 GHz and 5 GHz bands
• Whole-home coverage up to 2,200 square feet
• Internal antennas for a clean, space-saving design
• Easy setup with the free SURFboard Central mobile app
• Built-in parental controls including time limits and one-tap internet pause
• Access point mode for use behind an existing router
• Save up to $168 per year in modem rental fees
• 2-year manufacturer warranty

ISP Compatibility

The SBG7600AC2 is certified for use with major U.S. cable internet providers including Xfinity and Cox, and it is approved for plans up to 800 Mbps. Always confirm compatibility with your specific service plan before activating. For step-by-step help, see our Xfinity modem activation guide or our Cox modem activation guide.

Technical Specifications

Model	SBG7600AC2
Brand	ARRIS SURFboard
Manufacturer	CommScope
Modem Standard	DOCSIS 3.0
Channel Bonding	32 downstream x 8 upstream
Max ISP Plan Supported	800 Mbps
WiFi Standard	802.11ac (AC2350)
WiFi Bands	Dual-band, 2.4 GHz and 5 GHz
Ethernet Ports	Four 1 Gigabit ports
WiFi Coverage	Up to 2,200 sq ft
Antennas	Internal
Security	WPA2-PSK
Access Point Mode	Yes
Setup and Management	SURFboard Central app
Voltage	115 V
Color	Black
Warranty	2 years (for new devices)
UPC	612572215418

What's in the Box

• ARRIS SURFboard SBG7600AC2 cable modem and WiFi router
• Power supply
• Quick-start guide
• 2-year warranty card

Simple Setup with SURFboard Central

Setup is straightforward. Connect the SBG7600AC2 to your cable outlet and power, then download the free SURFboard Central app from the Apple App Store or Google Play. The app walks you through activating service with your provider, naming your WiFi network, and adding devices. Once you are online, the app provides real-time network monitoring, parental controls with time limits and pause options, and guest network management. No calls to your provider required.

Why Own Your Modem

Most U.S. cable providers charge $14 or more per month to rent a modem and router. Owning the SBG7600AC2 eliminates that recurring fee and typically pays for itself within the first year. You also gain control over firmware updates and the freedom to change providers without returning leased equipment.

Frequently Asked Questions

What internet speed does the SBG7600AC2 support?

The SBG7600AC2 supports cable internet plans up to 800 Mbps. It uses DOCSIS 3.0 with 32 downstream and 8 upstream channels.

Is the ARRIS SBG7600AC2 compatible with Xfinity?

Yes. The SBG7600AC2 is approved for Xfinity cable internet plans up to 800 Mbps. Confirm your specific plan tier on the Xfinity website before activation.

Is the SBG7600AC2 compatible with Cox?

Yes. The SBG7600AC2 is certified for use with Cox cable internet plans up to 800 Mbps.

Does the SBG7600AC2 work with Spectrum?

The SBG7600AC2 is primarily certified for Cox and Xfinity. Spectrum customers should verify compatibility against Spectrum's current approved modem list before purchasing.

How large a home will the SBG7600AC2 cover?

The SBG7600AC2 provides WiFi coverage up to 2,200 square feet. For larger homes or homes with multiple floors and thick walls, an additional access point or mesh extender may improve coverage.

How many devices can the SBG7600AC2 support?

The SBG7600AC2 is designed for busy households with many connected devices including smart TVs, gaming consoles, phones, laptops, and smart home gear. Four Gigabit Ethernet ports handle wired devices, and dual-band WiFi handles wireless ones.

Does the SBG7600AC2 have parental controls?

Yes. The SURFboard Central app provides parental controls including pausing internet access, scheduling time limits, and managing devices on your network.

Can the SBG7600AC2 be used in access point mode?

Yes. The SBG7600AC2 supports access point mode, allowing you to use it behind an existing router or to extend WiFi on an existing network.

What WiFi security does the SBG7600AC2 use?

The SBG7600AC2 uses WPA2-PSK encryption to secure your wireless network.

Does the SBG7600AC2 support telephone service?

No. The SBG7600AC2 does not include telephone or voice ports. If you need cable voice service, you will need a voice-capable modem instead.

How much can I save by owning the SBG7600AC2?

ARRIS estimates savings of up to $168 per year by replacing your rented modem. Actual savings depend on your provider's monthly rental rate.
